MF 375 PERFORMANCE: |
| Engine Power at 2200 rpm |
75 (B.S) HP |
| Torque at 1400 rpm |
290 Nm |
| PTO Power at rated |
69.5 hp* |
| Engine Speed |
|
| PTO Power at 540 rpm |
63.0 hp |
| * Engine certified to BS.AU 141a: (1971) |
MF 375 ENGINE: |
| Type |
Diesel / 4.248 |
| No. of Cylinders |
4 |
| Injection |
Direct |
| Bore |
101mm |
| Stroke |
127 mm (5.0 in) |
| Capacity |
4.07 Liter |
| Aspiration |
Natural |
| Compression Ratio |
16:1 |
| Starting Aid |
Thermostart |
| Throttle Control |
Hand and Foot |
| Cooling |
Water |
| Air Cleaner Type |
Oil Bath |
| Air pre-cleaner |
Over-bonnet, Centrifugal |
| Fuel Filter |
Dual, High Capacity |
| Exhaust |
Vertical, Muffler under Bonnet |
| Note: This is a premium heavy duty engine with tuffrided crankshaft for longer life in adverse conditions. |
MF 375 ELECTRICS: |
| Voltage |
12 V, Negative Earth |
| Battery |
110 Ah |
| Starter Motor |
2.8 kW |
| Alternator |
45 Amp |
| Light |
Head Lights, Side Lights |
| |
Brake Light, Direction |
| |
Indicators, Rear Work Lamp |
| Safety Start |
Transmission & PTO |
| Other |
Horn |
MF 375 CLUTCH: |
| Type |
Dual |
| Diameter |
305 x 254 mm |
| Lining Material |
Cerametallic |
MF 375 POWER TAKE - OFF: |
| Type |
Live PTO |
| Speed Shaft Diameter |
@ 540 rev/min is 1789 |
| No. of Splines |
Engine rev/min Single Speed |
|
35 mm (1.375 in) |
| |
6 |
MF 375 TYRES: |
| Front |
7.50-16 (6PR) |
| Rear |
16.9/14-30 (6PR) |
MF 375 TRANSMISSION: |
| Type |
Sliding Spur |
| No. of Gears |
8 Forward, 2 Reverse |
| Road Speed @ 2000 engine rpm with
16.9/14x30 rear tyres |
| Gear |
Speed (km/h) |
| Forward 1 (first low) |
2.3 |
| Forward 2 |
3.4 |
| Forward 3 |
4.7 |
| Forward 4 |
6.3 |
| Forward 5 (first high) |
9.3 |
| Forward 6 |
13.6 |
| Forward 7 |
18.6 |
| Forward 8 |
25.0 |
| Reverse 1 (low) |
3.2 |
| Reverse 2 (high) |
12.7 |
MF 375 HYDRAULICS: |
| Functions |
Draft Control, |
| |
Piston Control, |
| Pump Type Oil Flow |
Response Control, |
| Pressure |
Constant Pumping |
| Max. Lift Capacity |
Reciprocating |
| with lower links |
Ferguson Pump |
| horizontal |
16.7 litre/min |
| |
21.2 MPA at normal operating temperature
2145 Kg with Cat I & II
Interchangeable Balls |
MF 375 STEERING: |
| Type |
Power |
| Steering Wheel |
Fixed, Padded |
MF 375 FRONT AXLE: |
| Type |
Heavy Duty Box |
| |
Section, Adjustable |
MF 375 REAR AXLE & BRAKES: |
| Axle Type |
Straddle with epicyclic reduction unit |
| Brake Type |
Oil Immersed, Multi-Disc |
| Brake Pedal |
Pendant |
| Braking Area |
1774 sq.cm |
| Brakes Actuation |
Hydraulic |
| Parking Brake |
Hand Lever Operated |
MF 375 TRACK ADJUSTMENT: |
| Front: |
1271 - 1881 mm |
| Rear Pressed: |
1423 - 2134 mm (56 - 84 in) |
MF 375 INSTRUMENTATION: |
| Gauges |
Tachometer/Hourmeter, |
| |
Fuel Level, Battery Level, |
| |
Water Temperature |
| Warning Lights |
Direction Indicators, |
| |
Electric Charge, Headlight |
| |
Main Beam, Low Engine Oil |
| |
Pressure, Brakes Lights & |
| |
Auxiliary socket |
MF 375 WEIGHT & DIMENSIONS: |
| Weight |
|
| Gross Weight |
2355 Kg |
| Dimensions |
|
| Wheel base |
2170 mm |
| Overall Length |
3670 mm |
| Width – Min. |
1970 mm |
| Height |
|
| Over Exhaust |
2485 mm |
| Over Steering Wheel |
1730 mm |
| Turning Circle |
|
| With brakes |
7260 mm |
| Without brakes |
8095 mm |
| Ground Clearance |
|
| (under Gear Box) |
465 mm |
MF 375 CAPACITIES: |
| Fuel Tank |
108.0 liter |
| Engine Sump |
7.5 liter |
| Cooling System |
15.2 liter |
| Hydraulic System |
36.0 liter |
| Hydrostatic Steering reservoir |
2.0 liter |
| Oil bath air cleaner |
0.7 liter |
| Brake Oil |
0.25 liter |
MF 375 STANDARD EQUIPMENT: |
| Weight Frame without Weights, Standard Tool |
| Box with set of tools, Top Link, Top Link End |
| Cat-I, Cat I & II balls, Check Chains, Stabiliser |
| Chains, Spring Suspension Seat, Flat Top |
| Fenders & Operator’s Manual |
MF 375 OPTIONAL EQUIPMENT: |
- Cabin (A/C Non-A/C), Sun Canopy (ROPS Style)
- Front End Weights, 9 Hole Drawbar
- Swinging Drawbar, Pintle Hook, Auto Hitch
- Hydraulic Control Outlets/Spool Valves
- External Electric Switch, PTO Belt Pulley
- International Warranty Tool Kit |
|
|
 |
